ADSS aerial optical cable for reliable outdoor networks
The Extralink ADSS (All-Dielectric Self-Supporting) aerial optical cable is an ideal solution for building durable, high-performance outdoor data transmission networks. The cable, made of 24 fibers of G657A1 type optical fibers, is exceptionally resistant and, due to its self-supporting design, does not require a metal support cable or an electrically grounded structure.
The optimal combination of 3 kN tensile strength and just 9.8 mm outer diameter guarantees high mechanical load capacity and easy installation, making it safely applicable even for longer spans. This aerial optical cable is a perfect choice for providers, corporate networks, and professional installations.
Main features and benefits
- 24 optical fibers, 4 x 6 fiber arrangement – transparent structure and easy identification
- G657A1 optical fiber – small bending radius, optimized for modern FTTH and FTTx systems
- ADSS design – fully dielectric, self-supporting, does not require metal support cables
- 3 kN tensile strength – stable fixation and durable mechanical resistance
- 9.8 mm outer diameter – compact size, easier installation and manageability
- Excellent weather resistance – UV, moisture, and temperature resistant sheath
- Suitable for bridging long sections – placement in electrical fields and on poles
Areas of application
The ADSS aerial optical cable can be used in modern data transmission infrastructure. Thanks to its fully dielectric construction, it can be safely installed near high-voltage lines while providing high bandwidth, stable connections.
- Network backbone connections for providers
- Aerial construction of urban and suburban optical networks
- Optical sections of FTTH / FTTx systems
- Data connections between industrial parks and facilities
- Connections between institutional and corporate campus networks
- Communication networks of energy companies along high-voltage lines
Advantages of G657A1 optical fibers
The G657A1 category optical fibers used in the cable provide low signal attenuation even with a small bending radius. This is particularly important in installation environments where bends, pole suspensions, direction changes, or limited space are present.
- Better performance in tight bends and curves
- Reliable data transmission at high speeds (gigabit and multi-gigabit networks)
- Compatible with most common optical connectors and active devices
- Stable signal transmission over long distances with minimal maintenance requirements
Mechanical and environmental resistance
The 3 kN tensile strength aerial optical cable is designed to withstand wind loads, ice and snow loads, and temperature fluctuations. This reliability is especially important for outdoor, pole-mounted, and installations between electrical wires.
- High tensile strength for safe tensioning
- UV-resistant outer sheath for long-term outdoor use
- Resistance to moisture and corrosion
- Wide operating temperature range – suitable for various climatic conditions
Installation and manageability
The relatively small 9.8 mm outer diameter facilitates the cable's manageability, transport, and installation. The self-supporting ADSS design allows the cable to be directly secured to poles, brackets, and tension points without a separate support cable.
- Plan the route, considering spans and fixing points.
- Use appropriate ADSS clamps and tensioners.
- Place the cable between poles with the recommended tension.
- Install splice boxes, distribution cabinets, and strip the fibers.
- Perform optical splicing, connectorization, and signal measurements.
During installation, it is recommended to follow the manufacturer's specifications and relevant standards, as well as to use appropriate optical measuring instruments for network verification before commissioning.
Why choose this aerial optical cable?
- Professional solution for provider and corporate optical networks
- Modern G657A1 fibers for flexible, high-speed data transmission
- ADSS technology for safe, self-supporting aerial installation
- High mechanical load capacity and excellent environmental resistance
- Compact size for easier manageability and installation
If you are looking for a durable, reliable, and high-performance aerial optical cable for your outdoor data transmission network, this Extralink solution is a stable and cost-effective choice for the long term.
