Aerial optical cable for high demands – 36-fiber ADSS solution
This aerial, self-supporting optical cable is specifically designed for outdoor networks where high tensile strength, reliable data transmission, and long lifespan are important. The 36-fiber design (in 6×6 groups) allows for simultaneous service to multiple services, segments, or clients, making it an ideal choice for providers, industrial facilities, and municipal networks.
ADSS technology – self-supporting cable even on tensioned poles
Thanks to the ADSS (All Dielectric Self Supporting) design, the cable is completely metal-free, allowing it to be safely suspended on electric poles and near other overhead lines without causing electromagnetic interference or potential differences. The self-supporting structure ensures that the cable does not require a separate support cable or steel wire.
- Metal-free, dielectric construction
- Safe installation near high-voltage networks
- Self-tensioning without a separate support cable
- Reduced risk of lightning strikes and electrical interference
G657A1 optical fiber – high-performance data transmission
The cable contains G657A1 type bend-tolerant single-mode optical fibers, which are excellent for high bandwidth, long-distance data transmission. These fibers are compatible with most standard telecommunications networks and perform well in FTTH, FTTx, and backbone applications.
- Single-mode G657A1 optical fibers
- Good bending properties even in tighter bends
- Low attenuation, reliable signal transmission
- Compatibility with modern optical networks
36-fiber (6×6) structure – flexible network design
The 36 optical fibers are divided into six bundles of six fibers each, providing great flexibility in designing the logical structure of the network. Separate fiber groups can be ordered for different services, customer groups, or redundancy purposes.
- A total of 36 optical fibers
- 6×6 fiber arrangement for easier administration
- Well-segmented network structure
- Spare fibers can be left for future expansions
High tensile strength – 3 kN load capacity
The cable has a tensile strength of 3 kN, allowing it to bridge longer spans and withstand increased mechanical loads. This is especially important where stronger wind loads, icing, or frequent temperature fluctuations occur.
- 3 kN tensile strength for safe suspension
- Suitable for longer spans, on utility pole lines
- Greater resistance to wind and ice loads
Outdoor design – 9.8 mm outer diameter
The approximately 9.8 mm outer diameter results in a robust yet manageable structure. The high-density outer sheath resists UV radiation, moisture, and mechanical damage, ensuring that the cable operates stably in outdoor environments for a long time.
- Approx. 9.8 mm outer diameter
- UV-resistant, weatherproof outer sheath
- Resistance to moisture and temperature fluctuations
- Reliable operation with long service life
Typical areas of application
The aerial ADSS optical cable can be used in various telecommunications and data transmission projects. The following areas offer reliable solutions:
- Telecommunications backbone networks
- FTTH and FTTx access networks
- Connections between corporate and industrial facilities
- Aerial connections between municipalities, industrial parks, campus networks
- Communication systems for utility providers (electricity, gas, water)
Benefits for network operators and installers
The product design emphasizes easy installability, long-term reliability, and optimal price-performance ratio. This makes it an ideal choice for network operators, installers, and system integrators looking for a durable aerial optical solution.
- Fast, no separate support cable required installation
- Stable, high-speed data transmission with G657A1 fibers
- Cost-effective solution for medium- and long-term projects
- Flexibility for expansions due to the 36-fiber capacity
Why choose this aerial optical cable?
The 36-fiber ADSS aerial optical cable is an ideal choice if you want to build a reliable, high-capacity, and future-proof network. The high tensile strength, flexibility of G657A1 fibers, and outdoor UV-resistant design together guarantee long service life and stable operation.
