Voltage: 12.8V | Capacity: 280Ah | Warranty: 6 years | Manufacturer: Perfektium | Type: LiFePO4 | Connection: M8 screw | Weight: 31 kg | Dimensions: 355x330x190 mm | Operating temperature -35-75 °C | Total energy: 3584Wh | Peak discharge current: 600A | Normal discharge current: 200A | Recommended charging current: 80A | Maximum charging current: 140A
Integrated Battery Management System (BMS), Bluetooth 4.0
The installation of Perfektium PF batteries is extremely simple, requiring no additional components.
The internal switch disconnects the battery in case of excessive discharge, overcharging, or high temperature.
Batteries can only be connected in parallel.
The BMS monitors and controls each cell and protects them from damage, such as overload and overvoltage.
LITHIUM BATTERY
- UL standard
- 6 years warranty
- Directly replaces lead-acid batteries
- Lighter weight and easier handling
- Lithium iron phosphate is more stable
- Maximum lifespan of over 6000 cycles
- Long-lasting modular construction
- RS485 communication interface
- Screw opening option, perfectly designed internal structure
design
ELECTRIC HEATING FILM
Patented technology
- All Perfektium lithium batteries come with a heating module, allowing use even at temperatures as low as -35 degrees
- The heating film is made of IP material, ensuring even heating.
- The BMS has a heating control function to ensure that the battery does not discharge itself.
Built-in Bluetooth 4.0 Monitoring
- The most accurate state of charge indication
- Switch function for controlling charging and load
- Compatible with connecting multiple batteries simultaneously
- Real-time monitoring of all batteries, presenting summary data of each battery
